HiBy FC6
USB Headphone R2R DAC/AMP
- Darwin Architecture NOS/OS Mode
- MQA 8X unfolding
- FPGA reclocking
- Dual OPA1622
- All-platform support, plug-and-play
- Supports DSD up to DSD51, PCM up to 32bit /768kHz
HiBy FC6
Darwin audio architecture
DAP-class complete audio architecture onboard for a groundbreaking audio experience. We apply the Darwin architecture, the winner of endless accolades in the high-end DAP arena, for the first time in a portable headphone DAC/amp, utilizing R2R design for the DAC, ensuring a sound with emotion, warm, wet with loose naturalness, at the same time preserving the FIR filtering and NOS/OS switch, etc. of the Darwin system for maximum flexibility.
NOS mode
NOS mode is non-oversampling, responding more immediately and directly to signals, converting the digital signals to the analog output directly, bringing a more analog sound signature, It is more suitable for music files/streams of 192kHz sample rate or above.
OS mode
Oversampling mode easily removes aliasing artifacts via the tried and true combination of the oversampling and ultrasonic lowpass filter, HDR, and NOS/OS mode switch, yielding superior measured performance; enables all functions of the Darwin architecture, realizes personalized adjustments of sound signature, adapting to different earphones.
MQA 8X unfolding
Master-tape quality audio re-constitution, a take-you-to-the-concert / studio experience! HiBy FC6 supports 8x MQA unfolding to provide music reproduction on par with master tapes and live venues!
Darwin FIR filter & Darwin-HDR
Achieves up to 16x oversampling with numerous custom filters available to suit different music styles;ย Utilizing advanced algorithms exclusively applicable to the Darwin architecture to improve dynamic range, further enriching the retrieval of detail, attaining new levels of musicality.
FPGA reclocking
Dual independent high precision clocking. Equipped with dual crystal oscillators at 45.158MHz and 49.152MHz, for accurate clocking of 44.1x and 48x kHz music sources alike and vanishingly low jitter
All-platform support, plug-and-play
Smartphone audio dongle / Computer soundcard etc. No charging required--USB powered in real-time.
Dual OPA1622
Discrete headphone stage with dual OPA1622. Headphone stage on par with high-end DAPs, with 2 flagship-class OPA1622 headphone amp chips and 4-way independent current-mode amplification.
Hi-res audio support
Natively supports DSD up to DSD512 as well as PCM up to 32bit /768kHz, on par with HiFi home audio components, as well as all streaming music sources.
Technical Details
- 1 x HiBy FC6
- User Manual
Processing Time
This product is in Pre-order period. Pre-orders are provided for items that have not reached us and will take some time to be shipped out.
Pre-order Period: 1 month for Black. Green has been discontinued
Note:
- No cancellation of orders once ordered.
- All orders to be shipped out sequentially.
