Advanced CD Playback Technology

The EC Mini is equipped with high-quality components like a Philips CD drive and Sanyo HD860 Laser, ensuring top-notch CD and MQA-CD reading capabilities. This reflects Shanling's commitment to using proven, high-quality parts in their audio products

Specialized Audio Decoding System

Featuring a dual DAC setup with two ES9219 ESS Sabre DAC chips, the EC Mini excels in audio decoding. It supports detailed 32-bit/384kHz PCM signals and DSD256, delivering sound with low distortion and high signal-to-noise ratio.

Versatile Digital Audio Player

Beyond traditional CD playback, the EC Mini offers extensive digital capabilities. It includes support for up to 2TB microSD cards, Bluetooth V5.0, and bi-directional USB input. The Bluetooth supports high-definition audio protocols such as LDAC and AptX, and the device provides multiple output options including 3.5mm and 4.4mm headphone jacks and RCA analog pre-out.

Remote Control via Shanling App

The EC Mini is compatible with the Shanling Eddict Player app, available on Android and iOS. This feature transforms your smartphone into a remote control for managing CD and MicroSD card playback.

Robust Power Supply

Powered by a 6800mAh 18650 battery, similar to that in the Shanling H7, the EC Mini offers impressive battery life: up to 25 hours for MicroSD playback and 7.5 hours for CDs.

Exceptional Performance with Premium Components

Shanling Audio's expertise is evident in the EC Mini, which includes a LTA8092 Pre-Amp chipset, Dual RT6863 headphone amplifiers, and high-quality Panasonic and ELNA capacitors. These components ensure a high-quality, immersive listening experience.

Technical Details

Dimensions
250 X 205 X 52mm
Weight
1.2kg
Screen
2.33-inch LCD Touch display
MicroSD Card audio formats
DSD (".iso",".dsf",".dff")/ DXD / APE / FLAC / WAV / AIFF / AIF / DTS / MP3 / WMA/ AAC / OGG /ALAC / MP2 / M4A / AC3 / OPUS / TAK / CUE | *DST encoding of ISO is not supported.
Hi-Res Support
384kHz/32bit, DSD256
MicroSD Card Support
Up to 2TB cards
DAC
Dual ES9219MQ DACs
Bluetooth Codec Support
Bluetooth Receiver: LDAC / AAC / SBC | Bluetooth Transmitter: LDAC / aptX / AAC / SBC
RCA Output
Output level: up to 2.1 Vrms | Frequency Response: 20 Hz - 40 kHz (-0.1dB) | THD+N: 0.0005% | Channel Separation: 110 dB | Dynamic range: 114 dB | Signal-to-noise ratio: 114 dB
3.5mm Output
Output power: 140 mW@32n | Frequency Response: 20 Hz - 40 kHz (-0.1dB) | THD+N: 0.0006% | Channel Separation: 76 dB | Dynamic Range: 120 dB | Signal-to-noise ratio: 120 dB | Noise: >113 dB | Output impedance: less than 1Ω
4.4mm Output
Output Power: 248 mW@32Ω | Frequency Response: 20 Hz - 40 kHz (-0.1dB) | THD+N: 0.0005% | Channel Separation: 115 dB | Dynamic Range: 123 dB | Signal-to-noise ratio: 123 dB | Noise:>110 dB | Output impedance: less than 1Ω
Inside the Box
  • 1 x Shanling EC Mini
  • User Manual

30-Day Return Policy

You may return any non-customized product that is still factory sealed, within 30 days upon receiving it. For items that are damaged, incorrect, or faulty upon delivery, Linsoul will assess the issue and provide a solution accordingly.

1 Year Warranty

The Shanling EC Mini Comes with a 1 year warranty on the CD Player only. Warranty doesn't apply to the included accessories.

Processing Time

This product is in Pre-order period. Pre-orders are provided for items that have not reached us and will take some time to be shipped out.

Pre-order Period: 2-4 weeks.

Note:

  • No cancellation of orders once ordered.
  • All orders to be shipped out sequentially.
