Brand new industrial design

For never-ending streaming of music (ONLINE mode only)

USB Bluetooth transmitter

For high quality wireless sound from any computer

Advanced USB output

For use with any external USB DAC, now including compatibility with DLNA, Airplay and Bluetooth receiver modes.

Audio design based on 30+ Years in Hi-Fi

Japanese AKM AK4490EN, highly trusted DAC used across many levels of Hi-Fi products, assuring natural and smooth sound. With TI OPA1612 acting as low-pass filter, two pieces of ADI AD8397 amplifiers and high-quality Panasonic capacitors, Shanling M2x provides clean, powerful and dynamic sound

Technical Details

Audio Circuit
- single AKM AK4490EN DAC - single TI OPA1612 acting as the low-pass filter - dual AD8397 amplifier
Dimensions
98 x 60 x 16 mm
DAC model
96dB
Weight
147 g
Battery
-2400 mAh, fully charged in 2.5 hour -10.5 hours of playback in Single ended mode -7.5 hours of playback in Balanced mode
Hi-Res sound support
PCM up to 32bit/384kHz, DSD up to DSD256
Audio output Single ended (3.5 mm jack)
-Output power 180 mW @ 16 Ohm / 106 mW @ 32 Ohm -SNR 117 dB (A-weighting) -Output impedance 1 Ohm -Channel separation 70 dB (32 Ohm)
Audio output Balanced (2.5 mm jack)
-Output power 212 mW @ 16 Ohm / 120 mW @ 32 Ohm -SNR 116 dB (A-weighting) -Output impedance 2 Ohm -Channel separation 107 dB (32 Ohm)
Inside the Box
  • 1 x Shanling M2X
  • User Manual

30-Day Return Policy

You may return any non-customized product that is still factory sealed, within 30 days upon receiving it. For items that are damaged, incorrect, or faulty upon delivery, Linsoul will assess the issue and provide a solution accordingly.

1 Year Warranty

The Shanling M2X Comes with a 1 year warranty on the Digital Audio Players only. Warranty doesn't apply to the included accessories.
