Build in WIFI for new possibilities

 Supporting DLNA and AirPlay for the most practical music streaming from your phone or computer Connect Shanling M5S with your other devices and enjoy high-quality playback of any stored files of music streaming services

Improved touch 2.0

 Shanling M5s uses new MTouch 2.0 operating system developed by Shanling. Based on the user feedback from MTouch 1.0, a variety of gestures have been added to make everyday use more convenient and user-friendly New shortcuts, customizable main menu, new EQ made profiles and so much more. Thanks to OTA (Over The Air) updates, you will never need to use your computer again for firmware updates. Connect Shanling M5s to Wi-Fi and your device will be updated to the latest version with just one click.

Bluetooth connection Shanling M5s support SONY LDAC Qualcomm aptX \AAC

SONY LDAC Supporting Hi-Res audio files up to 24bit/96kHz and with three times higher data transmission than other Bluetooth technologies s Qualcomm aptX Advanced Bluetooth codec providing CD-like quality of sound and compatible with more than 540 brands worldwide AAC: A high compression ratio algorithm, essential for best compatibility with iOS devices

Two-way Connection over bluetooth

Connect Shanling M5s to any Bluetooth speaker and headphones for carefree wireless listening Or use Shanling M5s in Bluetooth receiver mode just pair it with your phone or tablet and enjoy your music, movies, Spotify, Tidal or even Youtube with top quality sound

Compact and Portable

Link processes and designs Aluminum alloy shell by using CNC, with the fashionable and compact appearance, the weight is only 15g, and the body is the same size as the USB disk, it is very convenient to carry and use, is the ideal choice for office and commuting, and is the gospel of mobile music enthusiasts

High-quality Hi-Fi Components

1. To fully restore audio signal from digital files, Shanling M5s is using special FPGA coding technology independently developed by Shanling, paired with two independent high-quality crystal oscillators from Japanese company KDS。

2.Low pass filtering: Using two TI OPA1612 dual-channel operational amplifiers with completely independent circuits to achieve lowest crosstalk and zero interaction between channels。

3.Amp circuit :Two ADI AD8397 dual op amps with low distortion and high output current assures clean and highly dynamic output, with enough power even for the demanding audiophile headphones

4.Shielding: To prevent undesirable noise interference and eletromagnetic radiation from affecting audio performance, parts of audio circuit are shielded with two copper plates ​

Balanced output

The four-channel LPF, four-channel amplifier and dual DAC form a fully balanced circuit, providing significantly increased power, higher resolution, improved channel separation better detail reproduction and overall more pleasing sound quality.

Technical Details

Size
59mm * 16mm * 117mm
Screen
3.2 inch, 320 x 480 resolution
Weight
178 g
Audio formats
DSF / DFF / ISO / DXD / APE / FLAC / WAV / AIFF/AIF/DTS/MP3/WMA/ACC/OGG/ ALAC / MP2 / M4C / AC3 / M3U / M3U8
Support up to
32bit / 768kHz、DSD256
Switchable gain
High and low
Storage
External Micro SD card, up to 2TB
D/A converter
2xAKM AK4493EQ
Digital filter
6 different filters
Output impedance
<0.30
Charging
DC5V2A/USBType-C
Bluetooth version
4.2
Codec support
LDAC (bidirectional) / aptX (transmit onlyAAC (bidirectional)
Output Power
240mw@16O / 130mW@32O / 13mW@3000
Output Power
240mw@16O / 130mW@32O / 13mW@3000
Output Power
240mw@16O / 130mW@32O / 13mW@3000
Signal to noise ratio
121dB (A weighting)
Channel separation
65dB(32Q)/85dB(300Q)
Dynamic Range
121dB
Distortion
<0.001%
Wi-Fi standard
IEEE802.11b/g/n
Wi-Fi features
DLNA/AirPlay/OTAfirmware upgrade
Battery Lifetime
Up to 17 hours (single-ended) /10 hours (balanced)
Battery capacity
3400mAH
Inside the Box
  • 1 x Shanling M5S
  • User Manual
