Industry Leading DAC Chip
The SMSL D300 comes with ROHM flagship DAC chip BD34301EKV, a 32-bit stereo D/A converter integrated with ROHM's own sound quality design technology. Excellent numerical performance is achieved for high-end audio. You can choose your favorite sound quality by switching between two FIR digital filters. Equipped with PCM I/F and DSD I/F, the maximum sampling frequency supports 768kHz and 22.4MHz respectively.
Precise Processing Circuit
The D300 features a brand new CKC-03 clock processing circuit pair with built-in shield to achieve lower clock jitter and improve power efficiency. Besides, they can also reduce consumption and make the clock jitter of the optical and coaxial as excellent as USB.
Low Noise Power Supply
The SMSL D300 follows with low noise power supply featuring the specially designed discrete component. With built-in shielding, the power supply can be stabilized. And the multiple low-noise stabilized power supplies can provide low-noise power supply for analog circuits.
Latest Bluetooth Chip
The SMSL D300 characterizes the Qualcomm's latest Bluetooth chip, which can support SBC, AAC, aptX, aptX HD, and LDAC. aptX is a bit rate efficient technology that ensures you receive high quality audio from your Bluetooth® device, so you have a better listening experience.
Updated Remote Control
SMSL D300 characterizes a high-resolution color fully-fitted display screen featuring tempered glass display panel with a newly designed high-quality knobs on the front. It also has a screen-off function. This remote controller with higher sensitivity and better hand feeling is fully operational using the remote control with comfort.
Technical Details
Output Level :XLR 4.0Vrms (Vol Fixed) 4.5Vrms(Vol variable)
RCA: 2.0vrms (Vol Fixed) 2.3vrms (Vol Variable)
THD+N: 0.00015%(-116dB)
Dynamic range: XLR 127dB
RCA: 125dB
SNR XLR: 127dB
RCA :124dB
Output impedance XLR :200Ω
RCA :100Ω
USB transmission: Asynchronization
USB compatibility windows: 7 /8/8.1 /10/11, Mac OSX、Linux
Bit depth USB: 1bit,16~32bit
Optical / Coaxial :1bit,16~ 24bit
Sampling rate :USB / PS PCM 44.1 ~768kHz
DSD :2.8224~22.5792MHz
Optical / Coaxial: PCM 44.1~192kHz
DSD :DSD64(DoP)
Bluetooth specification: BT 5.0(support SBC, AAC, aptX, aptX HD,LDAC)
Power Consumption :5w
standby power: <0.5w
Size :208x185x41mm (WxHxD)
Weight :1.05kg / 2.31lbs
- 1 x SMSL D300
- User Manual
