German Infineon's New Technology Class D Power Amplifier Chip

SMSL DA6 adopts a high-power digital power amplifier chip from the German Infineon brand. It is a newly designed silicon carbide class D power amplifier chip that enables the DA6 to produce a powerful signal amplification while achieving lower distortion and high SNR ratings.

Electronic Volume Control

SMSL characterizes electronic digital volume control on the DA6. The amplifier provides precise volume adjustment with a noise-free operation. the noise produced by the potentiometer can be completely eliminated.

Built-in Preset Multiple EQ Sound Mood

The DA6 come with multiple EQ presets built into its system. Users can use cycle through these easily using the fully-functioning remote control. E0 means no EQ, E t means custom EQ with adjustable Treble and Bass frequencies (-14dB to 14dB), E1 is for bass, E2 is for Super bass, E3 is for Rock, E4 is for soft EQ, and E5 is for clear EQ adjustments. Apart from these EQ presets, the DA6 also features three options for analog stereo tunings.

Small but Exquisite

As a highly-compact digital power amplifier, SMSL DA-6 has an exquisite finish with CNC machined whole aluminum alloy body. It weighs just under 500 grams and has a compact form factor. The DA6 is designed in such a way to look elegant and at the same time packs some serious juice.

Excellent & Clean Performance

SMSL DA6 follows a powerful performance under its compact form factor. The amplifier outputs up to 70W of stereo output power at 4Ω of load. It can suffice for most bookshelf speakers out there and presents the user with a clean performance.

Technical Details

Output power:
70W x 2(4Ω)
Frequency response:
20Hz-40KHz
BASS or TREBLE GAIN:
-14dB ~ +14dB
THD+N:
0.004%
Channel separation:
91dB(1KHz)
Input sensitivity:
400mVms
SNR:
103dB
Maximum input voltage:
Low gain-2Vrms
High gain-1 .2Vrms
Power consumption:
36W
Dimensions:
140X28x110mm (WxHxD)
Weight:
0.35kg
Inside the Box
  • 1 x SMSL DA-6
  • User Manual

30-Day Return Policy

You may return any non-customized product that is still factory sealed, within 30 days upon receiving it. For items that are damaged, incorrect, or faulty upon delivery, Linsoul will assess the issue and provide a solution accordingly.

1 Year Warranty

The SMSL DA-6 Comes with a 1 year warranty on the AMP & DAC only. Warranty doesn't apply to the included accessories.

Processing Time

This product is in Pre-order period. Pre-orders are provided for items that have not reached us and will take some time to be shipped out.

Pre-order Period: Expected to be available in early December

Note:

  • No cancellation of orders once ordered.
  • All orders to be shipped out sequentially.
