New Clock Processing Circuit

The SU-9n characterizes new CK-02 Clock Processing Circuit with Ultra-low phase noise and optimized clock system, which can speed up power supply processing, while improving power efficiency. It also can lower noise and power consumption. Specially designed discrete component linear regulated power supply and multiple low noise regulated power supplies to provide low noise power for analog circuits.

Qualcommโ€™s Latest Bluetooth Chip

The SMSL SU-9n equips with Qualcommโ€™s Latest Bluetooth Chip aptX, an audio technology designed to respond flexibly to the latest devices. You can get the most from your music by hearing the smallest details. Even while gaming, there is no audio or video delay ensuring a fully immersive experience.

High-End Components

The SU-9n features high-end components only for good sound quality. Firstly, cooperating with ES9311, the high-end ES9038PRO Dv/A chip from ESS Technology can be pushed to the limit. Specially designed discrete component linear regulated power supply and multiple low noise regulated power supplies to provide low noise power for analog circuits. Therefore, it brings wonderful audio experience in entertainment.

Precise Aluminum Alloy Shell

The SMSL SU-9n features precise CNC milled Aluminum Alloy shell. After outer oxidation and chamfering treatment, the product appearance is more delicate and smoother, meaning that SU9 is durable.

Multi-functional Remote Control

The SU-9n equips with updated remote control with the characteristics of higher sensitivity and better touch. Even from 10 meters away, you still can control it by remote.

Technical Details

Input:
USB / Optical / Coaxial / Bluetooth
Output:
RCA /XLR
Output level:
โ€ขPre mode
XLR 4.8Vms
RCA 2.3Vrms
โ€ขFixed mode
XLR 4.3Vms
RCA 2.0Vrms
THD+N:
0.000065%(-123.5dB)
0.000055%(-125dB) (A-WT)
Dynamic range:
XLR 130dB
RCA 123dB
SNR:
130dB
Output impedance:
XLR 207ฮฉ
RCA 142ฮฉ
USB transmission:
Asynchronization
USB compatibility:
windows 7 /8/8.1/10/11, Mac OSX, Linux
Bit depth:
USB 1 bit๏ผŒ16~32bit
Optical / Coaxial 1bit๏ผŒ16~24bit
Sampling rate:
โ€ขUSB
PCM 44.1~768kHz
DSD 2.8224~22.5792MHz
โ€ขOptical /Coaxial
PCM 44.1~192kHz
DSD DSD64(DoP)

Bluetooth specification:
LDAC. 24bit/96kHz(990kbps/660kbps/330bps)
aptX-HD 24bit/48 kHz_576kbps
aptX 6bit/44.1 kHz_352kbps
SBC 16bit/44.1 kHz_328kbps
AAC 1 6bit/44.1 kHz_320kbps
Consumption:
5W
Power:
๏ผœ0.5W
Size:
187.5X154X40mm (WxHxD)
Weight:
0.79kg
Inside the Box
  • 1 x SMSL SU-9n
  • User Manual

30-Day Return Policy

You may return any non-customized product that is still factory sealed, within 30 days upon receiving it. For items that are damaged, incorrect, or faulty upon delivery, Linsoul will assess the issue and provide a solution accordingly.

1 Year Warranty

The SMSL SU-9n Comes with a 1 year warranty on the AMP & DAC only. Warranty doesn't apply to the included accessories.
