Advanced DAC Decoding

The Black Pearl has a built-in USB audio bridge chip (CB5100) and dual DAC chips (CS43131) that provide low-power, high-performance decoding. Together, these three components rapidly enhance data processing and digital signal transmission, support high-resolution audio, and deliver richer, more detailed sound.

Exceptional Resolution

Capable of decoding PCM 384kHz/32bit and DSD64/DSD128/DSD256 formats, The Black Pearl captures every nuance with remarkable precision. It renders even the faintest background details and ensures smooth transitions between frequencies, maintaining a wide dynamic range and effective noise suppression for a truly pure listening experience.

Versatile Connectivity

Designed for broad compatibility, the device offers both a 4.4mm fully balanced differential output and a 3.5mm stereo headphone output. This dual-interface approach allows users to easily connect to a variety of devices, delivering the flexibility needed for any audio setup.

Intuitive Status Indicators

An integrated three-color status light simplifies operation: blue indicates standby, green shows PCM mode, and red signifies exclusive DSD mode. This clear, visual feedback streamlines user interaction without the need for complex digital displays.

Integrated Recording and Calling

Beyond high-fidelity playback, The Black Pearl supports built-in recording and calling functions following Android’s standard line control. This feature not only captures rich sound details during calls but also ensures natural voice reproduction, allowing you to enjoy seamless communication alongside your music.

Technical Details

DAC Chip
CS43131 ×2
USB Type
Type-C USB 2.
Supported Formats
32bit/384kHz PCM, DSD256
Dimensions
57mm × 23mm × 13mm
Weight
Approximately 25g (Cable not included)
Colors
Blue, Green, Red
Output Level (Load 32Ω)
4.4mm: 320mW; 3.5mm: 125mW
DNR (Load 600Ω)
4.4mm: 130dB @ 4Vrms; 3.5mm: 125dB @ 2Vrms
DNR (Load 32Ω)
4.4mm: 130dB @ 4Vrms; 3.5mm: 125dB @ 2Vrms
SNR (Load 600Ω)
4.4mm: 130dB @ 4Vrms; 3.5mm: 125dB @ 2Vrms
SNR (Load 32Ω)
4.4mm: 130dB @ 4Vrms; 3.5mm: 125dB @ 2Vrms
THD+N (Load 600Ω)
4.4mm: –110dB @ 2Vrms; 3.5mm: –110dB @ 1Vrms
THD+N (Load 32Ω)
4.4mm: –110dB @ 2Vrms; 3.5mm: –105dB @ 1Vrms
Operating Voltage
4.5V – 5.25V
Total Harmonic Distortion
–108dB (RL=32Ω, single end, 100mW)
Inside the Box
  • 1 x TRN Black Pearl
  • User Manual

30-Day Return Policy

You may return any non-customized product that is still factory sealed, within 30 days upon receiving it. For items that are damaged, incorrect, or faulty upon delivery, Linsoul will assess the issue and provide a solution accordingly.

1 Year Warranty

The TRN Black Pearl Comes with a 1 year warranty on the AMP & DAC only. Warranty doesn't apply to the included accessories.
